| Model | DHN-LVEH1P3K-EU-G1 | DHN-LVEH1P3.6K-EU-G1 | DHN-LVEH1PSK-EU-G1 | DHN-LVEH1P6K-EU-G1 |
|---|---|---|---|---|
| Battery Input Data | ||||
| Battery Type | Lead-acid/Li-ion | |||
| Battery Voltage Range (V) | 40-60 | |||
| Max. Charging Current (A) | 70 | 80 | 112 | 135 |
| Max. Discharging Current (A) | 70 | 80 | 112 | 135 |
| Charging Strategy for Li-ion | Self-adaption to BMS | |||
| PV String Input Data | ||||
| Max. PV Input Power (W) | 4800 | 5760 | 8000 | 9600 |
| Max. PV Input Voltage (V) | 500 | |||
| Start-up Voltage (V) | 120 | |||
| MPPT Voltage Range (V) | 120-425 | |||
| Max. Operating PV Current (A) | 18 | |||
| No. of MPPTs / Strings | 1/1 | 2/1 | ||
| AC Input/Output Data | ||||
| Rated Active Power (W) | 3000 | 3600 | 5000 | 6000 |
| Max. Apparent Power (VA) | 3300 | 3960 | 5500 | 6600 |
| Rated AC Current (A) | 13.6/13 | 16.4/15.7 | 22.8/21.8 | 27.3/26.1 |
| Peak Power (Off-grid) | 2 times of rated power | |||
| Grid Connection | L+N+PE | |||
| Efficiency & Protection | ||||
| Max. Efficiency | 97.60% | |||
| MPPT Efficiency | 99% | |||
| Protection | DC Polarity Reverse, Overcurrent, Thermal, Short Circuit, Ground Fault Monitoring, Island Protection | |||
| Ingress Protection | IP65 | |||
| Cooling Type | Intelligent Air Cooling | |||
