Basic Information
Model NO.:
12V100Ah
Discharge Rate:
High Discharge Rate
Shape:
Square Battery
Electrolyte:
Li-Ion
Installation:
Packaged
Nominal Capacity:
12V 100ah
Cycle Life:
5000 Times
Warranty:
5 Years
Weight:
9.9kg
Certificate:
CE/RoHS/MSDS/Un38.3
OEM/ODM:
Acceptable
Origin:
China
🌟
Key Features
-
✔
Longer Cycle Life: Offers up to 20 times longer cycle life and five times longer float/calendar life than lead acid battery, minimizing replacement cost.
-
✔
Lighter Weight: About 40% of the weight of a comparable lead acid battery. A "drop in" replacement for lead acid batteries.
-
✔
Higher Power: Delivers twice the power of a lead acid battery, even at high discharge rates, while maintaining high energy capacity.
-
✔
Wider Temperature Range: Operates efficiently between -20ºC to 60ºC.
-
✔
Superior Safety: Lithium Iron Phosphate chemistry eliminates the risk of explosion or combustion due to high impact overcharging or short circuit situations.
🔋
Applications
⚡ Wheelchairs and scooters
⚡ Solar/wind energy storage
⚡ Back-up power for small UPS
⚡ Golf trolleys & buggies
⚡ Electric bikes
⚙️
Technical Specifications
| Category |
Parameter |
Value |
| Cell Specs | Model | 3.2V 100Ah |
| Capacity (0.5C) | 100Ah |
| Typical Impedance | 0.35mΩ |
| Battery Material | LiFePO4 |
| Pack Specs | Combination Method | 4S1P |
| Nominal Voltage | 12.8V |
| Max. Charge Voltage | 14.6V |
| Max. Charge Current | 100A |
| Max. Working Current | 100A |
| Gross Weight | 11.5kg |
| Charge Temperature | 0°C to 45°C |
| Discharge Temperature | -20°C to 60°C |
❓
Frequently Asked Questions
1. What's your payment term?
We accept T/T, Letter of Credit, PayPal, Western Union, and more.
2. What's your minimum order quantity (MOQ)?
Our minimum order quantity is 1 unit.
3. What is the typical delivery time?
Delivery usually takes 5-25 days, depending on quantity and stock. In-stock products are sent within 2 days of payment.
4. Do you offer OEM or ODM services?
Yes, we have a professional R&D department and fully support OEM and ODM customization.
5. Can I test a sample before bulk ordering?
Yes, samples can be offered for testing, and the sample fee will be returned when you place a bulk order.
6. How do I select the right model for my needs?
Please contact us before purchasing to confirm specifications and technical details to ensure the model matches your application.
